Installing flood lights increases the security of your home and enhances its beauty. To install a flood light, first of all, you have to decide where you want to install it. If you want to install the floor light in someone’s house or your own, then you have to call an electrician and start installing the floor light.
The method of installing the flood light is very simple, you can easily install it anywhere. Flood light is easily installed. The steps to install a flood light are given in the blog below. Keep reading the step-by-step block and learn how to install a flood light.
How To Install Flood Lights?
LED flood light is generally used to provide light to large places like gardens, airports, factories, outside houses, etc. It is also used to provide security to large places because LED flood lights reach every corner.LED flood lights can be easily installed anywhere with the help of LED My Place. Its design is very simple and easy to understand.
- Choose the Location: LED flood lights by choosing a good place to install the LED plate. Usually, LED flood lights are installed on the walls of the garage outside a factory or on the roof. This light works very well near the entrance of the gate because more people come and go near these areas. To choose the place for the LED flood light, we should keep it in a place where the light can get electricity easily and where this light is needed the most, like a dark corner or an alley where it is dark.
- Turn off the Power Supply: Before starting the installation of the LED flood light, switch off the power supply to avoid any electric shock.
- Prep the Hole and fit the Junction Box: Punch a hole in a outside wall of your factory or home. Use a machine to punch holes that can power the junction box.
- Connect the Wiring:
Tools And Materials Needed To Install Flood Lights
Before installing the flood light please make sure you have all the required tools to install it, after that we can install the flood light.
- Ladder: A ladder is a tool that helps us to reach higher places, if any LED light is to be placed at a place, then the bird is a very important tool to reach there.
- Screwdriver: Screwdriver is a tool which is used to loosen or tighten a screw. With the help of this tool we can connect any bracket. It is used to cover the panel of LED light and to open and close the LED Panel box.
- Drill: Drill is a tool with which we can make holes at a place. If we need to connect a wire or make a hole for installing a wire, then we can do the required work using this.
- Wire cutter: We use wire cutter to separate electrical wires. It is required when the wires need to be exposed from inside. With its help, we can check the wires and join them easily by matching them.
- Electrical Tape: Electric tape has electronic insulation properties. It is used to protect the wires between LED lights and the power source. With its help, we can protect the electrical wires from dust, dirt and moisture.
- Voltage Tester: Voltage meter is a current resistance. We use it to measure the current in LED lights to see if there is any electricity in the outlet. Voltage tester also helps you in troubleshooting any kind of fault in wiring or light. we can increase or decrease the light at any time with voltage tester.
How To Mount The Fixture And Ensure Stability?
Selecting the Mounting Location
Choosing the right location for your blue light picture is important for both efficiency and efficiency. This will help you get a good spot
- Height Matters: Your flood light should be installed at least 8 to 10 feet above the ground. This height helps in covering a larger area.
- Aim for the Area:Flood lights should be placed in a place where they can provide light to an unlit area such as an entrance or a dark area
- Consider the Elements: Avoid placing the flood light in an area where there is heavy rainfall or direct sunlight. This will increase the longevity of the picture.
- Check the Surface: Make sure the surface you plan to place the picture on is strong and can bear the weight of the light.
Mounting Techniques
- Mounting on Walls: Now that you have chosen the right spot, you can mount the flood light in different locations.
- Mark the Spot: Use a pencil to mark the location where you want to put the holes.
- Drill Holes: Use a drill to make the holes for the screws making sure the holes are aligned with the mounting bracket.
- Insert Anchors: If you are mounting in a driver or recess, insert anchors into the wall to ensure stability
- Attach the Bracket: Screw the mounting bracket in place using the screws.
- Mount the Light: Finally, attach the flood light to the bracket and tighten the screws to secure it.
- Mounting on Eaves (Under the Roof Edge)
- Locate the Joists: Use a stud finder to locate the wood joints underneath the light.
- Mark and Drill: Mark where the screws will go and drill holes in the joints.
- Secure the Bracket: Paste into the joint to make sure it is tight and secure.
- Attach the Fixture: Mount the floodlight onto the bracket and tighten it with the provided screws.
- Mounting on Poles:
- Use a Mounting Strap: A mounting strap or clasp is best for poles.
- Secure the Fixture: Place the strap around the shell at the desired height and tighten it to hold the light firmly in place.
Securing the Fixture
Follow these steps to make sure your fixture is weatherproof.
- Tighten All Screws: After mounting, double-check that all screws and screws are tight. Loose screws can cause instability.
- Use Waterproof Sealant: Apply waterproof cement around the edges of the fixture where it meets the mounting lugs. This prevents water from getting in and causing damage.
- Check the Wiring: Make sure electrical connections are properly insulated. Use weatherproof connectors or leads to protect them from moisture.
- Regular Maintenance: Periodically inspect the fixture for any signs of wear or looseness and replace damaged components as needed.
How To Run Electrical Wiring For Your Outdoor Flood Lights?
Safety Precautions:
Before beginning any electrical work, it is important to follow safety instructions to avoid accidents and hazards. Always turn off the power at the circuit breaker before working with electrical wiring. Use a voltage tester to make sure the circuit is not live. Wear safety glasses to protect yourself from electrical shock or debris. Consider talking to a licensed electrician if you are unsure about what to do.
Wiring and Electrical Connections:
1.Choose the Right Wires: Typically use 12-gauge or 14-gauge outdoor wiring, depending on load and distance. This wire should be used for the neck location.
2. Connect the Wires:
- Grounding: Ground wire from blue lightStart by connecting the ground wire from the power source, usually green or bare copper. Connect these wires to the grounding screw in the electrical box.
- Hot Wire: Connect the black wire from the flood light to the black wire from the power source using a wireless cable.
- Neutral Wire: Connect the white wire from the flood light to the white wire from the power source.
3. Ensure Proper Insulation: Once the wires are connected one by one, protect them with wire netting and wrap them with electrical tape to ensure they are well insulated. This prevents them from coming in contact with the circuit that is working.
Pulling Wires Through Conduit:
1. Plan Your Route: Measure the route from the power source to the flood light. Measure the distance to make sure you have enough wire and conduit.
2. Install Conduit: Use outdoor-rated wire to avoid damaging the wire. Start by installing conduit along the planned route. Secure with conduit clamps to hold it in place.
3. Feed the Wire:
- Cut the wire to the proper length so there is extra room for connections
- Feed the wire through the conduit. Use fish tape to pull the wire through if the conduit is long or has bent.
- Attach the wire to the fish tape, then pull the fish tape through the conduit, bringing the wire with it.
4. Connect to the Power Source:
- Once the wire is run through the conduit, connect it to the power source. This usually involves connecting the wires inside an outdoor-rated junction box.
- Make sure all connections are secure and properly insulated.
5. Mount the Floodlight: Finally, mount the floodlight according to the manufacturer’s instructions. Make sure it is securely attached and all connections are weatherproof.
How To Connect The Conduit And Place The Junction Box?
Installing the Electrical Box
1. Choose the Location: Choose a spot on the wall or post where you want to place the electrical box. This should be close to where you want to place the floodlights.
2. Mark the Spot: Use a pencil and mark where the box will be placed. Make sure the box is level and in the right position.
3. Drill the Holes: Use a drill to drill holes in the marked spots. These will be used to secure the electrical box to the wall or post.
4. Mount the Box: Place the box over the holes and secure it in place. Make sure it is tight and doesn’t move.
Connecting the Conduit
1. Measure and Cut the Conduit: Use hexagons to cut the conduit to the correct length depending on the distance between the power source and the electrical box.
2. Attach Conduit Connectors: Slide a conduit connector onto each end of the conduit. These connectors will secure the conduit to the collector box’s electrical storage.
3. Secure the Conduit to the Box:
- Insert one end of the conduit into the knockout hole in the electrical box.
- Tighten the connector to secure the conduit.
- This will ensure the conduit is firmly connected and does not come loose.
Placing the Junction and Outlet Box
1.Proper Placement: Place the junction box where it is easily accessible for future maintenance but out of reach of water or heavy debris. This is important for both safety and functionality.
2.Positioning for Safety: Make sure the box is not too close to the ground where it could be exposed to moisture. Also, keep it away from flammable materials.
3.Check Stability: After mounting, pull the box slightly to make sure it is stable and will not move or come loose.
Can I Install A Floodlight Myself, Or Do I Need An Electrician?
DIY Installation vs Professional Help
1. DIY Installation:
- Advantages: Saves money, gives you control over the project, and can be done at your convenience.
- Disadvantages: Requires electrical knowledge; mistakes can create safety risks.
2. Professional Help:
- Advantages: Ensures the job is done safely and correctly; comes with experience and tools.
- Disadvantages: Costs more and requires scheduling.
3. Safety Considerations
- DIY risks: Electrical shock, improper wiring, or installation that can cause fire or malfunction.
- When to call an electrician: If you’re not sure about the wiring, the installation involves complicated setup, or you need to install motion sensors.
4. When to Hire an Electrician?
- Motion sensor lights: These often require more complicated wiring.
- Complex wiring: If your project involves many lights or complicated wiring, it’s best to call a professional.
- Permits and code compliance: An electrician makes sure everything is up to code, which is important for safety and legal reasons.
Where Should Flood Lights Be Positioned On A House?
Optimal Locations for Security
- Front and back entrances: Place flood lights above doors to illuminate entry points and deter intruders.
- Driveways and garages: Place lights to cover the driveway and garage area for better visibility at night.
- Backyards and side yards: Place lights in dark areas of the yard to eliminate hiding places and cover blind spots.
Aiming Light Fixtures for Maximum Effectiveness
- Driveways: Angle the lights down and outward to cover the entire length of the driveway.
- Backyards: Adjust the lights to cover the entire yard, focusing on areas near fences and gates.
- Entryways: Aim the lights to fully illuminate the door without casting shadows, where intruders might hide.
Which Is Better LED Or Traditional Flood Lights?
LED vs. Traditional Flood Lights
- LED Flood Lights:
- Advantages: Energy-efficient, long lifespan, bright light and low maintenance cost.
- Disadvantages: Higher initial cost but benefits in the long run.
- Traditional Flood Lights:
- Advantages: Lower initial cost.
- Disadvantages: Higher energy consumption, shorter lifespan and need for frequent replacement.
Choosing the Right LED Flood Light
- Wattage: Choose the wattage based on the area you need to cover; higher wattage for larger areas.
- Brightness: Look for lumens instead of watts; more lumens means more light.
- Coverage Area: Consider the beam angle and range to ensure full coverage of your desired area.
How Much Does It Cost To Fit An LED Floodlight?
Cost Overview
- Materials: LED floodlight prices range from 1600 to 12000 depending on quality and features.
- Tools: If you don’t already have basic tools, they can cost 800 to 4000.
- Labor: Hiring an electrician can cost between 8000 and 25000, depending on the complexity of the job.
Factors Affecting Cost
- Type of floodlight: Higher wattage, smart features or being weatherproof can increase the price.
- Installation Complexity: More complex wiring or hard-to-reach locations can increase labor costs.
Location: Labor rates may be higher in urban areas than in rural areas.
How To Maintain And Adjust Your Flood Lights For Longevity?
Regular Cleaning and Inspection:
Clean your flood lights regularly to remove dirt and debris, which can reduce brightness and efficiency. Inspect for cracks, rust, or damage to the casing to prevent moisture from getting in and causing electrical problems.
Replacing Bulbs and Components:
Replace burnt-out bulbs promptly to maintain consistent lighting. Check and replace other components such as seals and gaskets that may deteriorate over time to prevent water damage and ensure the lights remain sealed and functional.
Using Electrical Test Equipment:
Use a multimeter to test the voltage and continuity of the flood lights. This ensures they are receiving the correct electricity and helps identify any electrical problems early, preventing further damage.
Frequently Asked Questions About How To Install Flood Lights
How To Efficiently Install Flood Lights?
To install the flood light efficiently, firstly, make sure the power is off. Mount the fixture securely to a junction box or wall bracket, connect the wires following the manufacturer’s instructions, and test the light before finalizing the installation.
Where Should Flood Lights Be Positioned On A House?
Flood lights should be placed at the corners of the home or above entry points, such as doorways and garages. Aim them downward at a 45-degree angle to cover the desired area without causing glare or disturbing neighbors.
